Ogma MCP Server Setup

The Ogma MCP server (ogma-mcp) lets compatible AI assistants inspect scoped Ogma project context: proxy traffic, findings, workflows, Replay sessions, Automate runs, scope, notes, and related security data.

MCP is for external tools such as Codex, Claude Code, Cursor, and other Model Context Protocol clients. It is not the same feature as the in-app Workspace AI assistant.

For the full resource and tool list, see MCP resources and tools.

When to Use MCP

Use MCP when an external assistant should help you:

• Summarize captured traffic.
• Triage findings.
• Draft evidence-based report text.
• Review workflows and Replay sessions.
• Prepare scoped actions that you explicitly approve.

Use Workspace AI when you want the embedded assistant window inside Ogma instead.

Requirements

• Ogma daemon running (default: http://127.0.0.1:8181)
• The ogma-mcp binary (built from source)

Build

cargo build --bin ogma-mcp --release

The binary is at target/release/ogma-mcp.

Run

# Connect to Ogma running on the default port
./ogma-mcp

# Connect to a custom address
./ogma-mcp --api-url http://127.0.0.1:9090

# Use a larger body preview
./ogma-mcp --body-preview-bytes 2048

The server exits immediately if it cannot reach the Ogma API.

In-App MCP Settings

Packaged Ogma builds can manage MCP from Settings > MCP. Use the settings screen when you want Ogma to start or stop the embedded MCP process for the active instance.

Use the standalone ogma-mcp binary when your AI client expects to launch the MCP server directly.

Ogma also exposes MCP management through its local REST API. These endpoints are used by the settings screen and the in-app AI bridge:

Endpoint	Purpose
GET /mcp/status	Return { running, pid, config } for the embedded MCP child process.
POST /mcp/start	Start the embedded MCP child process with the persisted permission and rate-limit settings.
POST /mcp/stop	Stop the embedded MCP child process.
GET /settings/mcp	Return the persisted MCP configuration.
PUT /settings/mcp	Save MCP configuration. Public bind and public write-tool configurations require explicit confirmation fields.
GET /mcp/tools	Return the current MCP tool catalog plus the active config used by the REST bridge.
POST /mcp/tools/call	Call one MCP tool through the REST bridge with { "name": "...", "arguments": { ... } }. Returns { "result": "..." }.

Default persisted MCP configuration:

{
  "bind_host": "127.0.0.1",
  "port": 3000,
  "allow_write_findings": false,
  "allow_export_data": false,
  "allow_send_requests": false,
  "allow_run_workflows": false,
  "allow_intercept_control": false,
  "max_sends_per_minute": 5,
  "max_workflow_runs_per_minute": 5
}

PUT /settings/mcp accepts those same fields. If bind_host is 0.0.0.0 or ::, include "allow_public_bind": true in the request body. If that public bind also enables write-capable tools, include "acknowledge_write_tool_risk": true.

Claude Code

Add to ~/.claude.json:

"mcpServers": {
  "ogma": {
    "type": "stdio",
    "command": "/path/to/ogma-mcp",
    "args": [],
    "env": {
      "OGMA_API_URL": "http://127.0.0.1:8181"
    }
  }
}

Reload Claude Code. Verify with: "What projects does Ogma have?"

Cursor

Create ~/.cursor/mcp.json:

{
  "mcpServers": {
    "ogma": {
      "command": "/path/to/ogma-mcp",
      "args": [],
      "env": {
        "OGMA_API_URL": "http://127.0.0.1:8181"
      }
    }
  }
}

Restart Cursor. Verify in Settings > Tools & MCP.

Read-Only Mode

By default, the MCP server is read-only. These operations are not available unless explicitly enabled:

• Sending requests (Replay)
• Driving the embedded browser, crawler, auth capture, and active probe helpers
• Running workflows
• Creating or modifying findings
• Modifying scope or match-replace rules
• Modifying or forwarding intercepted traffic
• Deleting data
• Accessing secret environment variable values
• Exporting data

Body content is capped at 512 bytes by default. Use --body-preview-bytes to adjust.

Finding Write Tools

To enable AI-assisted finding creation, restart ogma-mcp with write permissions:

./ogma-mcp --allow-write-findings

Or set the environment variable:

OGMA_MCP_ALLOW_WRITE_FINDINGS=1 ./ogma-mcp

Write tools available

Tool	Description
ogma_preview_finding_from_evidence	Preview a finding draft from an HTTP entry (read-only, always available)
ogma_create_finding	Create a finding with severity, status, tags, and evidence links
ogma_update_finding	Update an existing finding
ogma_add_finding_tag	Add tags to a finding without replacing existing tags
ogma_link_finding_evidence	Link HTTP entry, Replay attempt, Automate result, or WS message to a finding

Example: AI-assisted finding creation

With --allow-write-findings:

1. "Analyze HTTP entry {id} for security issues. If you find a real issue, use ogma_create_finding to document it."
2. The AI will call ogma_get_http_entry to inspect the request
3. If evidence supports a finding, it will call ogma_create_finding with the evidence linked

Still not available with finding writes only

• Replay sending
• Workflow execution
• Export creation
• Finding deletion
• Bulk update
• Any proxy or scope mutations

Export Tools

To enable AI-assisted export job creation, restart ogma-mcp with export permissions:

./ogma-mcp --allow-export-data

Or set the environment variable:

OGMA_MCP_ALLOW_EXPORT_DATA=1 ./ogma-mcp

Export tools available

Tool	Permission required	Description
ogma_preview_export_plan	None (read-only)	Preview what would be included in an export
ogma_list_export_jobs	None (read-only)	List recent export jobs
ogma_get_export_job	None (read-only)	Check export job status
ogma_get_export_download_info	None (read-only)	Get download URL for completed export
ogma_create_export_job	export_data	Create an export job

Supported export kinds and formats

Kind	Description	Formats
http_history	All proxied HTTP requests	json, csv, raw_http
search	Filtered HTTP requests	json, csv, raw_http
findings	Security findings	json, csv
automate_results	Automate session results	json, csv

Note: raw_http format is only valid for http_history and search kinds.

Security warning

Export files may contain full HTTP request and response bodies, which can include passwords, tokens, and personal data. Handle export files with appropriate care.

Still not available with export permissions only

• Export file deletion
• Export file renaming
• Streaming export content through MCP
• Replay sending
• Workflow execution

Replay Request Sending

Warning: this enables sending real outbound HTTP traffic through Ogma Replay.

To enable:

./ogma-mcp --allow-send-requests

With custom rate limits:

./ogma-mcp --allow-send-requests --max-sends-per-minute 3 --max-sends-per-session 10

Or via environment variables:

OGMA_MCP_ALLOW_SEND_REQUESTS=1 OGMA_MCP_MAX_SENDS_PER_MINUTE=3 ./ogma-mcp

Prerequisites

1. Ogma proxy must be running
2. An active scope must be configured in Scopes (required for all sends)
3. The target host must be in the active scope

Send tools

Tool	Permission	Description
ogma_preview_replay_send	send_requests	Prepare a send, get confirmation token
ogma_send_replay_request	send_requests	Execute send with confirmation token
ogma_create_replay_session_from_history	send_requests	Create Replay session
ogma_create_replay_session_raw	send_requests	Create Replay session from a raw request definition
ogma_repeat_request	send_requests	Repeat a captured request with optional changes
ogma_replay_with_modifications	send_requests	Replay a captured request with field-level overrides
ogma_http_request	send_requests	Send a direct HTTP request
ogma_fetch_url	send_requests	Fetch a URL and return status, headers, and preview
ogma_follow_redirect	send_requests	Follow a redirect chain and report each hop
ogma_bulk_send_requests	send_requests	Send a bounded batch of requests
ogma_fuzz_parameter	send_requests	Replace a placeholder with wordlist values
ogma_multipart_upload	send_requests	Send multipart form-data requests for upload testing
ogma_websocket_connect	send_requests	Connect to a WebSocket URL and exchange messages
ogma_login_replay_auto	send_requests	Submit a browser login form and capture an auth profile
ogma_auth_capture_profile	send_requests	Capture browser cookies, storage, auth tokens, and CSRF candidates
ogma_auth_apply_profile	send_requests	Apply a captured auth profile to the browser
ogma_auth_refresh_csrf	send_requests	Refresh CSRF candidates from browser state
ogma_authz_matrix_test	send_requests	Replay one request as multiple auth profiles
ogma_run_active_probe_workflow	send_requests	Run bounded vulnerability-specific active probes
ogma_browser_navigate and browser interaction tools	send_requests	Drive the embedded browser and capture resulting traffic
ogma_crawl_site	send_requests	Crawl a scoped target through the embedded browser
ogma_get_replay_session	None	View Replay session metadata
ogma_get_replay_attempt	None	View Replay attempt metadata
ogma_list_replay_sessions	None	List Replay sessions

Two-step workflow

Every send requires two tool calls to prevent accidental sends:

1. ogma_preview_replay_send - review the request, get a confirmation token
2. ogma_send_replay_request - confirm and send with the token

Confirmation tokens expire in 5 minutes and are single-use.

Rate limits

Default: 5 sends per minute, 20 sends per session (resets on restart).

To adjust: --max-sends-per-minute N --max-sends-per-session N

Example session

User: Resend HTTP entry abc123 and check the response
AI: (calls ogma_preview_replay_send with http_entry_id="abc123")
    - shows request preview, confirmation token, scope status --
AI: (calls ogma_send_replay_request with token and hash)
    - shows response status, timing, response preview --

Still not available with request-sending permissions only

• Workflow execution
• Finding creation or update
• Deletion

Direct request tools can target arbitrary URLs, but scope checks and rate limits still apply where the tool sends traffic through Ogma's guarded send path. Keep the active scope narrow before enabling these tools.

Intercept Control

Warning: intercept control lets an MCP client forward, drop, or modify live traffic currently held in Ogma's intercept queue.

To enable:

./ogma-mcp --allow-intercept-control

Or via environment variable:

OGMA_MCP_ALLOW_INTERCEPT_CONTROL=1 ./ogma-mcp

Intercept tools

Tool	Permission	Description
ogma_get_intercept_status	intercept_control	Read request, response, and WebSocket intercept state
ogma_set_intercept_enabled	intercept_control	Enable or disable intercept modes
ogma_list_intercept_queue	intercept_control	List currently held items
ogma_get_intercept_item	intercept_control	Inspect one queued item
ogma_forward_intercept_item	intercept_control	Forward a queued item, optionally modified
ogma_drop_intercept_item	intercept_control	Drop a queued item
ogma_intercept_and_modify	intercept_control	Wait for a matching item, modify it, and forward it

Workflow Execution

Warning: workflow execution runs workflow logic. Some workflows send HTTP traffic or create findings.

To enable:

./ogma-mcp --allow-run-workflows

With custom rate limits:

./ogma-mcp --allow-run-workflows --max-workflow-runs-per-minute 2 --max-workflow-runs-per-session 10

Workflow execution tools

Tool	Permission	Description
ogma_get_workflow_safety	None (read-only)	Classify workflow side effects
ogma_preview_workflow_run	run_workflows	Preview and get confirmation token
ogma_run_workflow	run_workflows	Execute with confirmation token
ogma_cancel_workflow_run	run_workflows	Cancel a running active workflow

Cross-permission requirements

Workflows that use sdk.requests.send also require --allow-send-requests. Workflows that use sdk.findings.create also require --allow-write-findings.

Detection is based on static text analysis - see the advisory note below.

Safety classification advisory note

Workflow safety classification inspects JavaScript source code text for patterns like sdk.requests.send. This detection is not exhaustive - obfuscated or dynamically constructed SDK method calls may not be detected. Always review workflow JavaScript source before running untrusted workflows.

Still not available with workflow permissions only

• Passive workflow manual triggering
• Automate execution
• Deletion
• Env var mutation

Example Prompts

Once connected:

• "Show me the last 20 HTTP requests to example.com"
• "Are there any high or critical findings in this project?"
• "Which workflows are currently enabled?"
• "Check if the HTTPQL query req.method.eq:\"POST\" is valid"
• "Summarize the security state of the current project"
• "Analyze HTTP entry {id} for security issues"

Troubleshooting

Connection refused: Start Ogma first (ogma --data-dir ./ogma-data).

MCP client shows no tools: Confirm the path to ogma-mcp is correct in your client config.

Empty results: Ogma needs traffic captured first. Browse with your proxy configured to forward traffic through Ogma.
